Hycontrol REFLEX User Manual

Ref: INDEX - REFLEX/SCANFLEX MANUAL
EDITION 1: JYLY ’97
REFLEX/SCANFLEX
PROGRAMMABLE LEVEL CONTROL SYSTEM
INDEX
I n t r o d u c t i o n 1
Installation & Wiring - Single point 2 - 3
- Multipoint 4 - 11
Pre-Start Guide 12 - 13
Programming - Principles & Definitions 14 - 19
- Parameter Index 20
- Parameter Definitions 21 - 33
Programme Examples 34 - 36
Fault Finding & Commissioning 37 - 47
APPENDIX 1 - Transducer Specification 48 - 54
- Temperature Sensor 55
APPENDIX 2 - Reflex Description & Specification 56 - 57
- Scanflex Multiplexor SM-10 58 - 61
- Scanflex Relay Module SR-10 62 - 64
- Scanflex Analogue Module SA-10 65 - 67
APPENDIX 3 - Linearisation of Vessels 68 - 70
APPENDIX 4 - Parameter Settings 71 - 72

Hycontrol REFLEX Specifications

General

Brand	Hycontrol
Model	REFLEX
Category	Controller
Language	English
