Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 19
Display Description
REFLEX/SCANFLEX On power-up REFLEX indicates that the instrument is
programmed on single point and SCANFLEX indicates
that the instrument is programmed as multipoint.
PROG Precedes entry to programme mode.
RUN Precedes return to run mode.
Pr.XX Parameter number, 2 digits
CODE Requests the entry of the security code.
==== No value
FULL Numerical overflow
-FUL Negative numerical overflow
PRES Indicates a parameter reset
TRES Indicates a totaliser reset
TEST System performing a requested test
GAIN Precedes display of gain value being used.
Programming Sequence
The programming of REFLEX/SCANFLEX is controlled by the parameters listed later in this
section.
The parameters are divided into the following distinct groups.
Pr's 01 - 07 Determine the number of points to be monitored, the type of
transducer used on each point, the function of the instrument
and the maximum and minimum distances and units.
Pr's 08 - 29 Configure the designation of the relays for each point being
measured and sets their operation points and failsafe modes.
Pr's 30 - 34 Configure the analogue output for all points.
Pr's 37 - 39 Enables and reads the output of temperature compensation sensors
if fitted.
Pr's 40 - 44 Programmes each point for volume conversion.
Pr's 49 - 53 Configures the Scanner for a multipoint application.
Pr's 62 & 63 Serial communications.
Pr's 65 - 69 Echo detection and processing.
Pr's 70 - 97 Miscellaneous and test parameter
Pr 99 System reset
Note: Use Pr.50 to copy data from one point to other points.
