Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 28
Multipoint Scanner Configuration
These parameters are relevant only if Pr.1 = 2 to 10
Pr.49 Point Data Reset (Applicable only to point selected ) ( D= '====')
The values of all POINT parameters which are particular to the point selected will be
returned to their factory default values.
Position cursor under '===='.
Press 'CE' to clear '====' and then press 'ENT'
CONTROL parameters, which are designated for all points, will not be changed.
Pr.50 Point Data Copy (D=0)
This parameter allows the programme entered for one point to be copied to other
points, as follows:-
a) Total Data Copy
On point 1 select Pr.50 = "0", position cursor under '0' and press 'ENT'. All
points as defined by Pr.1 will then have the same programme copied to them.
b) Partial Data Copy
To be used for instance where points 1 & 2 are different but points 3 onwards
are identical. On point 3 select Pr.50 = "0", position cursor under '0' and press
'ENT', then point 3 to number of points defined by Pr.1 will all have the same
programme copied to them.
c) Individual Data Copy
This will copy all programme data from one individual point to another. eg. To
copy the data from point 4 to point 8, select point 4 and then select Pr.50 and
enter 8 into it, Points 4 and 8 will then have the same data.
Pr.51 Number of Modules (D=1)
(Minimum 1, Maximum 15)
This parameter defines the total number of extra modules (SM-10, SR-10 and SA-10)
which are connected to the Scanflex Controller. (See Module identification
instructions Page 10)
Do not include the Reflex Controller in the total.
Pr.52 Maximum Time On One Point (D=15)
The maximum time the Scanflex Controller will remain on one point attempting to
achieve a valid echo. Adjustable from 10 to 100 seconds.
To Next Page
