Hycontrol REFLEX User Manual

Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 36
Pr.52 = 15 Determines the maximum time the Controller can dwell on any
individual Point.
Pr.68 = 2 Echo processing algorithm for liquids as POINT 01
This completes the programming for POINT 01 and has set all the "Control" parameters
which must be the same for each point i.e. in this example Pr.8, 11, 23, 24, 28, 29, 30, 51 and
52.
There are now two ways to programme the remaining 6 points:-
1) Since in this example all points are identical you could go to Pr.50 and enter "0"
which will copy the same data to all remaining 6 points.
or
2) If any of the data is different for a point you can press the "#" key and change from
point 1 to point 2 etc and then re-enter data for all the parameters relevant
to point 02 etc.
NOTE Parameters which can be individually set for each point are typically shown as
follows:-
POINT = 01
Pr.04 = 20
EMPTY DISTANCE
Parameters which are common to all points are call CONTROL and are
typically shown as follows:-
CONTROL = 01
Pr.08 = 1
RELAY ONE DESIG
