Appendix 2
Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 67
SCANFLEX ANALOGUE MODULE SA-10
SPECIFICATION
Enclosure : IP65 Polycarbonate
Dimensions : 300H x 230W x 85D (mm)
Weight : 1.75Kg
Power Supply : 110/230V a.c. selectable 50/60Hz 12VA
Supply Variation : +10% -15%
Fuse Rating : 250mA slow-blow
Ambient Temperature : -40
o
C to +70
o
C
Analogue Outputs : 10 off 4-20mA into 750 ohms, short circuit protected.
Group opto-isolated. (All have common -ve and shield)
Indication : 2 off red l.e.d.'s to indicate power on.
1 off green l.e.d. to indicate communications with
Controller.
Switches : 1 off module number selector
2 off mA test
Connections : Two part screw terminal connectors
