Identifying components
LVU-CD-40
en(us)
Page 22 / 68
BeWa LVU-CD-40 4035823a en-us 2016-01-08.doc 2016-01-08
Item Designation
100 Clogging indicator, visual, for the filter housing
200 Clogging indicator, visual, for the coalescing housing
1000 Collecting pan
1330 Inlet
2000 Coalescing housing
2110 Sight glass, upper phase boundary
2111 Sight glass, lower phase boundary
2310 Venting, coalescing housing
2560 Outlet
3210 Water drain
3350 Emptying, coalescing housing
4000 Motor pump assembly
4010 Inspection opening
5000 Filter housing (pre-filter)
5001 Air bleed, filter housing
5002 Emptying, filter housing
7000 Main switch with motor protection
