Push In/Quick Connect Fittings:
Connecting Push-In Fittings:
Dis-connecting Push-In Fittings:
Push in collet
Push tube firmly into the fitting, all the way to tube stop. The collet (gripper) has
stainless steel teeth which hold the pipe firmly in position whilst the ‘0’ Ring provides
a permanent leak proof seal. Pull tubing to check for security. If some tube pulls out
then push all the way in again until it stops.
It is good practice to test the system prior to leaving site and/or before use.
Ensure system is depressurized by turning off source water before removing fittings.
Push in the collet evenly toward the fitting. With the collet held in this position the
tube con be removed by simply pulling You can use a collet release tool (available
from your dealer) or small crescent wrench. The fitting can then be re-used. If the
tube has been removed several times you may see score marks on the ends. This
can lead to leaks so cut the end off the tubing totally square with a sharp blade
using care.
Remove Pipe
7
