15
EUROPE – R.C.D. INSTALLATION - TYPICAL
Important Note: Installaon of the R.C.D. - Circuit Breaker, including ampere sizing and selecon of conductor size and
type, must be performed by a qualified electrician in accordance with Naonal, Regional and Local Codes and Regulaons
in effect at the me of installaon.
NOTICE
230 VOLT 50 Hz SINGLE PHASE RCD WIRING
230 VOLT 50 Hz DUAL PHASE RCD WIRING
230 VOLT 50 Hz THREE PHASE RCD WIRING
