Rainswitch Control Switch (lower right)
"ON" position - Allows Rainswitch to function and break water cycling if "WET".
"OVERRIDE" position - Allows for manual operation of controller if Rainswitch is
"WET".
NOTE: If no Rainswitch is used, switch must be in position for controller to function.
WIRE CONNECTION DIAGRAMS
(Caution : always disconnect power at source prior to installing or servicing this
unit)
