Page 15 KN INSTALLATION AND OPERATION INSTRUCTIONS
Water piping (continued)
Figure 11 Suggested piping — multiple boilers — primary/secondary piping, reverse-return boiler headers
Multiple boilers, primary/secondary
Sizing and  ow control
Size circulators to provide the  ow needed for the individual zones.
Provide  ow/check valves where shown to prevent gravity circulation or
forced  ow in idle zones.
DHW operation, when required
e piping shown throughout this manual allows for domestic water
heating without  ow through the heating loop(s).  is is important for
summertime operation of DHW tanks.
Make sure to incorporate  ow/check valves as shown.  ese prevent forced
ow in idle zones.
LEGEND • • • • • • •
1 KN boiler
2 Boiler circulator
3 System circulator
5 Indirect- red DHW tank
(when used)
6 DHW circulator
7 Flow/check valve
8 Cold water  ll line
9 Expansion tank (shown with diaphragm-type — see
page 12 for piping a closed-type tank) Expansion tank
(shown with diaphragm-type — see page 12 for piping
a closed-type tank)
10 Air separator with automatic air vent (Replace air vent
with piping to the tank  ing on closed-type expansion
systems.)
11 Low water cut-o (when required)
12 Extra high limit (when required)
16 Boiler postpurge circulator (see page 11) KN
-
2 only
17 Header sensor, required
Isolation valve
Temperature gauge
5
****
*
