HydroTherm KN-2 - Replacement Parts

P/N 42-9450 8/08 Copyright 2008 Hydrotherm
Page 46 KN INSTALLATION AND OPERATION INSTRUCTIONS
KN - 2 Replacement parts
15
ITEM PART No. DESCRIPTION QTY
1 20-1022
TRIDICATOR
1
2 03-1752
RIGHT JACKET PANEL
1
3 60-5625
ABS SIDE MEDALLION
1
4 42-5238
OFF LABEL
1
5 58-1555
MAIN POWER SWITCH
1
6 42-5237
ON LABEL
1
7 70-1223
BASE ASSEMBLY
1
8 03-1750
FRONT JACKET PANEL
1
9 03-1754
PORT COVER
2
10 57-4114
3/8 - 16 X 3/4 HX HD FLANGE BOLT
7
11 70-1421
BLANK BOX ASSEMBLY
1
12 60-5626
DOCKING STATION
1
13 03-1755
VIEWPORT COVER
1
14 57-1501
5/16-18 X 1 1/4 HX BOLT
2
15 01-1649
SIGHT GLASS HOLDER
1
16 59-1106
INNER SIGHT GLASS GASKET
1
17 60-4280
SIGHT GLASS
1
18 59-1107
SIGHT GLASS GASKET
1
19 57-3657
10-32 THUMBSCREW
3
20 03-1765
FILTER BOX TOP COVER
1
21 59-1090
UPPER FILTER BOX GASKET
1
22 59-1089
COMBUSTION AIR FILTER
1
23 60-5624
ABS UPPER COVER
1
24 59-1091
FILTER BOX ADAPTER GASKET
1
25 70-1237
FILTER BOX ADAPTER
1
26 57-2913
1/4-20 X 1 NYLOK SC HD CAP
SCREW
4
27 54-3234
1/2” FLEX GAS LINE
1
ITEM PART No. DESCRIPTION QTY
28 70-6689
GAS TRAIN SUPPORT BRACKET
1
29 02-1580
DUNGS GAS VALVE
1
30 02-1582
INLET SHROUD - GAS VALVE
1
31 70-6674
MESH BURNER
1
32 58-2215
1 3/4 HOLE CAP
1
33 22-1203
PRESSURE RELIEF VALVE 30 P.S.I.
1
34 03-1753
LEFT SIDE JACKET PANEL
1
35 70-1238
IGNITOR ASSEMBLY
1
36 02-4276
24V IGNITION CONTROL
1
37 03-1756
IGNITION COVER
1
38 02-3928
HIGH LIMIT
1
39 02-3927
OPERATOR - THERMISTER
1
40 03-1776
IGNITION BOX COVER
1
41 09-1520
TACO 005 W/INTERNAL FLOW
CHECK
1
42 56-3346
FLUE ADAPTER
1
43 03-1761
TERMINAL BOX COVER
1
44 03-1760
TERMINAL BOX
1
45 26-3211
24 AC TRANSFORMER
1
46 02-4288
BREAK - OUT BOARD
1
47 02-5210
PRESSURE SWITCH
2
48 45-1274
CERAMIC FIBER CHAMBER
1
49 59-1103
UPPER BURNER GASKET
1
50 01-1640
UPPER CASTING COVER
1
51 58-1837
100 WATT AMETEK BLOWER
1
52 57-3413
#6 X 1/2” BLK OXIDE SCREW
2
53 03-1759
BUTTON GUARD
1
54 70-1422
REMOVABLE BOILER CONTROL
1
