P/N 42-9450 8/08 Copyright 2008 Hydrotherm
Page 40 KN INSTALLATION AND OPERATION INSTRUCTIONS
Starting the boiler (continued)
Figure 32 Throttle adjustment and ame window
Measure ame current
Electrical shock hazard e electrical box contains line-voltage
wiring and contacts. Use caution when working in the electrical box to
avoid contact with line-voltage elements. Power must be on to measure
ame current.
With the boiler operating at low re (low- re jumper in place), measure the ame
current.
Remove the upper electrical panel cover (upper right side of boiler).
A ach microammeter leads to the ame current test pins of the Fenwal ignition
module as in Figure 32.
e ame current should be approximately 6 microamps, and never less than
1 microamp. Record the ame current value on the back page of this manual.
If ame current is acceptable, continue with setup. If ame current is too low,
check the ignition electrode/ ame rod assembly following the instructions in the
Maintenance section of this manual.
Check boiler modulation
Remove the low- re jumper from the electrical connection panel (see Figure 28).
e boiler ring rate should change to meet demand. e HeatNet control display
will show the percentage of maximum ring rate (between 20% and 100%).
Test ame failure modes
Flame loss
With the boiler running in normal operation, close the manual gas valve on the
incoming gas line.
Within 0.8 second a er the ame goes out, the boiler gas valve should shut o .
e HeatNet control will restart operation with prepurge, then continue through
a normal start cycle.
With the manual gas valve closed, the boiler should a empt ignition three times,
then lockout, as described below.
Ignition failure
Make sure there is a call for heat.
Turn the boiler on/o switch OFF.
Close the manual gas valve on the gas supply line.
Turn the boiler on/o switch ON.
e boiler should start a regular cycle.
When the boiler a empts ignition, no ame will occur. Within 4 seconds of
ignition start, the control will close the boiler gas valve and a empt another start.
A er three failed ignition a empts, the Fenwal control will lockout.
e boiler will shut o and the HeatNet control display will show “LOCKOUT.”
Open the manual gas valve.
Reset the controls by turning the boiler on/o switch o , then on again.
e boiler should restart and operate normally.
Test control & interlock operation
Test HeatNet operating limit function
Allow the boiler to re until the supply temperature reaches the upper end of the
control band.
1.
2.
3.
4.
5.
1.
2.
1.
2.
3.
4.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
1.
e boiler should gradually cycle to minimum input ( ring
rate = 20%), then turn o .
Test external controls
Lower the se ing of external limit controls below the supply
water temperature. Verify that the controls shut down as
required.
Test operation of low water cut-o s, ow switches and other
external devices.
Test external gas pressure interlocks, if used.
Test/verify operation of combustion air dampers and end
switches, if used.
DHW applications
For DHW applications, verify that the boiler operates on
demand from the indirect water heater and shuts o as
required.
Fill out the installation certi cate
Complete the checklist and installation certi cate on the
back page of this manual.
2.
1.
2.
3.
4.
1.
1.
