Page 50 KN INSTALLATION AND OPERATION INSTRUCTIONS
KN - 4 Replacement parts (continued)
15
ITEM PART No. DESCRIPTION QTY
1 60-5646
ABS UPPER COVER
1
2 03-1806
RIGHT SIDE JACKET PANEL
1
3 70-1672
FRONT JACKET WELDMENT
1
4 03-1809
DISPLAY MOUNT PLATE
1
5 60-5645
CONTROL OVERLAY
1
6 58-1536
ILLUMINATED ROCKER SWITCH
1
7 42-5330
ON-OFF LABEL
1
8 02-4288
BREAK OUT BOARD
1
9 57-3657
THUMB SCREW FOR FILTER BOX
4
10 57-3630
10-32 UNC-0.375 SCREW GREEN
1
11 58-1080
COPPER LUGS
2
12 02-4291
CONTROL BOARD ASSY
1
13 70-1680
BASE ASSY
1
14 56-4725
CPVC BOTTOM PLUG
1
15 53-1323
1 1/2 X 3 1/4 WELD NIPPLE
1
16 56-4726
CPVC TOP PLUG
1
17 56-5534
3/8 NPT X 1/2 BARD FITTING NYLON
1
18 57-2495
DRAIN TUBE NUT
1
19 59-1111
GASKET - DRAIN TUBE
1
20 56-5536
DRAIN INSERT TUBE
1
21 53-1076
1/2 X CLOSE NIPPLE
1
22 57-4114
3/8 - 16 X 3/4 FLANGE HEAD
HEX BOLT WASHER HD
11
23 42-5230
LIGHTING INSTRUCTION
1
24 42-2999
KN-RESIDENTIAL RATING LABEL
1
25 03-1804
LEFT SIDE JACKET PANEL
1
26 03-1808
JACKET SPACER
7
27 57-3659
5/16 X 1 1/4 ALL SCREW BUTTON HD
2
28 57-4701
5/16 LOCK WASHER
2
29 01-1649
CASTED SIGHT GLASS HOLDER
1
30 59-1106
INNER SIGHT GLASS GASKET
1
31 57-3407
#8 X 1/2 TYPE B
PHILLIPS HEAD SCREW
34
32 60-4280
VIEW PORT GLASS
1
33 59-1107
INSULATION SIGHT GLASS
1
34 03-1802
REAR JACKET PANEL
1
35 20-1022
TRIDICATOR PRESURE/TEMP. GAUGE
1
36 56-4226
1 1/4 X 3/4 BUSHING
1
37 53-1120
3/4 NPT X CLOSE NIPPLE
1
38 22-1203
3-4 X 3-4 F TO F 30 PSI 535K BTU
PER HOUR RELIEF VALVE
1
39 45-1272
CERAMIC CHAMBER
1
40 59-1096
CERAMIC CHAMBER GASKET
1
ITEM PART No. DESCRIPTION QTY
41 70-1209
MESH BURNER
1
42 01-1642
UPPER CASTING COVER
1
43 58-1837
100W PRE-MIX BLOWER
1
44 01-1651
INLET ADAPTER CASTING
1
45 02-1590
DUNGS INTAKE ADAPTER GB 057
1
46 02-1589
DUNGS AIR INTAKE ADAPTER GB 057
1
47 02-1581
DUNGS GAS VALVE GAS VALVE
MODEL GB-057 HO XP, 24 VAC
1
48 59-1115
PIPE SEALING GROMMET
1
49 03-1811
FILTER BOX COVER
1
50 59-1113
FILTERBOX GASKET - CLOSED
CELL NEOPRENE
1
51 59-1109
COMBUSTION AIR FILTER
1
52 03-1810
FILTER BOX
1
53 42-5223
FILTER BOX LABEL
1
54 57-4708
1/4 LOCK WASHER
4
55 57-2915
1/4-20 X 5/16 UNC SC HD CAP SCR
4
56 02-3928
THERMAL SNAP SWITCH
1
57 02-3927
THERMAL PROBE
1
58 53-1274
1 1/4" X 3" SUPPLY NIPPLE
2
59 57-4624
1/4 ID X 9/16 OD FLAT WASHER
4
60 03-1816
IGNITION COVER BOX
61 57-2731
10-32 BRASS KNURL NUT
4
62 56-5741
DOUBLE BARBED
1-4 X 1-8 NPT FEMALE
2
63 57-2630
THIN BRASS HEX NUT 1/8-27
2
64 56-5742
1-4 TUBE X 1-4 NPT
1
65 56-5740
1/4 TUBE X 1/8 NPT
2
66 03-1818
IGNITION BOX STATIONARY BRKT
1
67 56-3345
4" 90 DEG FLUE ADAPTER
1
68 56-4605
1/4" SQ HD PIPE PLUG
1
69 56-4560
3/8 C I PLUG
1
70 03-1822
WIRE RACEWAY
1
71 70-1238
IGNITION ASSY
1
72 59-1112
IGN. BLOCK GASKET
1
73 54-1601
1/4 ALUMINUM TUBING
FLUE ADAPTER
1
74 54-1601
1/4 ALUMINUM TUBING FILTERBOX
1
75 26-3211
24V 50 WATT BASLER TRANSFORMER
1
76 02-4279
COMMUNICATIONS BOARD
1
77 02-4276
IGNITION CONTROL
1
78 02-1510
PRESSURE SWITCH
2
