HygroMatik CompactLine - Page 60

Page 60
* C01 C02 C06 C10 C17 C22 C30 C45 C58 Article No.
Description
Control, electrical supply below 230V
1 E-2504092 Main contactor 100 A, 230V
1 B-2507081 Main contactor 65A, 230V
1 B-2507061 Main contactor 35A, 230V
1 1 B-2507041 Main contactor 20A, 230V
1 B-2524209 Cable for electrode 35A/6mm²
Basic Control
1 1 1 1 1 1 1 1 1 B-2526201 Basic Mainboard
51 1 1 1 1 1 1 1 1 1 E-2502412 Control switch, double pole
1 1 1 1 1 1 1 B-2120901 Mounting plate (Basic)
1 1 B-2120915 Mounting plate (Basic)
Comfort Control
1 1 1 1 1 1 1 1 1 B-2526201 Basic Mainboard
51 1 1 1 1 1 1 1 1 1 E-2502412 Control switch, double pole
1 1 1 1 1 1 1 B-2120903 Mounting plate (Comfort)
1 1 B-2120917 Mounting plate (Comfort)
1 1 1 1 1 1 1 B-2526401 Display (Comfort)
1 1 B-2526489 Display (Comfort)
Comfort Plus Control
1 1 1 1 1 1 1 B-2526201 Basic Mainboard
51 1 1 1 1 1 1 1 E-2502412 Control switch, double pole
1 1 1 1 1 1 1 B-2120905 Mounting plate (Comfort Plus)
1 1 1 1 1 1 1 B-2526403 Display (Comfort Plus)
DS-Control
1 1 1 1 1 1 1 1 1 B-2526211 DS-Basic Mainboard (PCB)
51 1 1 1 1 1 1 1 1 1 E-2502412 Control switch, douple-pole
x x x x x x x B-2526401 Display (Comfort), grey, until Dec. 2009
x x x x x x x B-2526403 Display (Comfort Plus), grey, until Dec. 2009
x x B-2526487 Display (Comfort), yellow
x x x x x x x B-2526445 Display (Comfort), yellow, since Jan. 2010
x x x x x x x B-2526447 Display (Comfort Plus), yellow, since Jan. 2010
x x x x x x x x x E-0605228 Temperature sensor for DS
x x x x x x x x x B-2505207 Holder for temperature sensor incl. mounting set
x x x x x x x x x E-0605232 Temperature Sensor ATF 2 for surface mounting
x x x x x x x x x E-2505206 Fuse for light, fan, essence injector 1.6A, 5x20mm
x x x x x x x x x E-3516020 Fuse for essence injection 2.5A, 2x20mm
x x x x x x x E-2504039 Fuse for transformer (E-2504154) 5A, 5x20mm
x x x x x x x E-2504200 Transformer 230/24V/130VA
