HygroMatik CompactLine - Page 61

Page 61
* C01 C02 C06 C10 C17 C22 C30 C45 C58 Article No.
Description
Essence Injection
x x x x x x x x B-2604091 pump, peristaltic DSP9111; 230V/50Hz; 3l/h
x x x x x x B-2604083 pump, peristaltic DSP9111; 24V/50Hz; 3l/h
x x x x x x x x E-2604072 hose for peristaltic pump DSP9431
x x x x x x x x E-2604074 hose for peristaltic pump DSP9111
x x x x x x x x E-2604076 hose connector for silicon hoses, 6mm
x x x x x x x x E-2604070 hose, silicon, for essence; 6x1,5
x x x x x x x x B-2604067 T-piece for essence injection (DN25)
x x x x x x x x B-2604069 T-piece for essence injection (DN40)
Accessories
x x x x x E-2604012 Steam hose DN25, per m
x x E-2604013 Steam hose DN40, for SPA application since 04.2010, per m
x x x x E-2604013 Steam hose DN40, per m
x x x x x x x x x E-2604002 Condensate hose DN12, per m
x x x x x E-2404004 Steam hose clamp DN25
x x E-2604016 Steam hose clamp DN40, for SPA application since 04.2010
x x x x E-2604016 Steam hose clamp DN40
x x x x x x x x x E-2304015 Condensate hose clamp
x x x x x B-2604025 Steam solenoid valve 0-0,4bar, compl. for steam hose DN 25
x x B-2604040 Steam solenoid valve 0-0.4bar, compl. for steam hose DN40, for SPA
application since 04.2010
x x x x B-2604040 Steam solenoid valve 0-0.4bar, compl. for steam hose DN40
x x x x x E-2604042 Connectors for steam distribution T-piece DN25, stainless steel
x x E-2604023 Connectors for steam distribution T-piece DN40, stainless steel, for SPA
application since 04.2010
x x x x E-2604023 Connectors for steam distribution T-piece DN40, stainless steel
x x x x x x x x x E-2604021 Connectors for condensate T-piece DN12
÷ ÷ ÷ 1 B-2208005 Cylinder star
1 1 B-2208007 Cylinder star
1 B-2208013 Cylinder star
1 B-2208009 Cylinder star
1 B-2208011 Cylinder star
1 1 B-3304061 Super flush complete
1 1 B-2304063 Super flush complete
1 1 1 1 1 B-2304065 Super flush complete
x x x x x x x B-2304079 Nozzle for Super Flush
x x B-2304089 Nozzle for Super Flush
56 x x x x x x x x x B-2304031 Water connection hose, flexible, 0.6 m 3/4", with connector
x x x x x x x B-3320406 Filling cup complete
If
y
ou order an
y
s
p
are
p
arts,
p
lease s
p
ecif
y
t
yp
e and serial number of the unit.
* see Exploded View
** If the Super Flush System is installed, consider to order also a new nozzle (B-2304079), please.
*** Maintenance kit contains: Electrodes without hand nuts, O-ring for adapter, O-ring seal for
cylinder base, O-ring seal for cylinder flange, 3 Cylinder flange clamps (pos.18)
