HYOSUNG RT125D - Spoke Nipple; Replacement of the Lamp; Head Lamp

59

SPOKE NIPPLE
Inspect the spoke nipple for loosening and
retighten the spoke nipple in case of
loosening.
Spoke nipple
tightening torque
0.25 ~ 0.30 kgfm
2.5 ~ 3.0 Nm
If the spoke nipple loose, it will increase
damage of the spoke and rim and
decrease the riding stability.
WARNING
HI
LO
Position
Brake / Tail lamp
Turn signal lamp
License plate lamp
Head
lamp
12V-35W 1
12V-35W 1
12V-5W 1
12V-21/5W 1
12V-10W 4
12V-5W 1
NAMES CAPACITY
Requirement electric power of the lamp
shown in the following chart.
When replace the damaged lamp, always
use the equal capacity.
The use of a lamp other than rules may
cause excessive voltage at the electric
system or damage the lamp.
REPLACEMENT OF THE LAMP
TURN SIGNAL
LAMP
TURN SIGNAL LAMP
LICENSE
PLATE
LAMP
BRAKE / TAIL
LAMP
HEAD LAMP
