Hypertherm Duramax Series User Manual

OPERATION
3-6 Duramax Retrofit Torch Operator Manual
45A Shielded Air flow rate - slpm/scfh
Stainless Steel
Hot 177 / 376
Cold 201 / 427
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
0.5
1.5 3.8 250
0.0
9000 130 12500 129
1 9000 130 10800 130
1.5 0.1 9000 130 10200 130
2 0.3 6000 132 8660 131
3
0.4
3100 132 4400 132
4 2000 134 2600 134
6 0.5 900 140 1020 139
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches % seconds ipm Volts ipm Volts
26GA
0.02 0.08 400
0.0
350 130 500 129
22GA 350 130 450 129
18GA
0.1
350 130 400 130
16GA 350 130 400 130
14GA
0.06 0.15 250
0.2 250 132 360 131
12GA
0.4
140 132 206 131
10GA 100 133 134 134
3/16 in. 0.5 52 135 58 135
1/4 in. 0.6 30 141 35 140
220817
Shield
220854
Retaining cap
220941
Nozzle
220857
Swirl ring
220842
Electrode
4
5
A
220817
Shield
220941
Nozzle
220857
Swirl ring
220842
Electrode
220953
Ohmic-sensing
retaining cap
4
5
A

Hypertherm Duramax Series Specifications

General

Cooling	Air-cooled
Type	Plasma cutting torch
Series	Duramax
Compatibility	Powermax systems
Torch Lengths	15' (4.6 m), 25' (7.6 m)
Consumables	Nozzles, electrodes, shields, retaining caps, swirl rings
Torch Models	Duramax Lock
Compatible Systems	Powermax65, Powermax85, Powermax105
Nozzle Types	FineCut
Electrode Types	Standard
Shield Types	Standard
Length	15 ft (4.6 m) standard, 25 ft (7.6 m) optional
