Hypertherm Duramax Series User Manual

OPERATION
3-16 Duramax Retrofit Torch Operator Manual
Low Speed FineCut
Stainless Steel
Metric
Material
Thickness
Current
Torch-
to-Work
Distance
Initial Pierce Height
Pierce Delay
Time
Recommended
Cut Speed Voltage
mm A mm mm % seconds (mm/min) Volts
0.5
30
0.5 2.0 400
0
3800 69
0.6 3800 69
0.8 0.1 3800 69
1
40
0.15 3800 69
1.5
0.4
2900 69
2 2750 69
3
45
0.5 2550 80
4 0.6 1050 80
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce Height
Pierce Delay
Time
Recommended
Cut Speed Voltage
A inches inches % seconds ipm Volts
26GA
30
0.02 0.08 400
0.0
150 69
24GA 150 69
22GA
0.1
150 69
20GA 150 69
18GA
40
0.2 145 69
16GA
0.4
115 69
14GA 110 69
12GA
45
0.5 120 80
10GA 0.6 75 80
220953
Retaining cap
220857
Swirl ring
220842
Electrode
220948
Shield
220930
Nozzle
220854
Retaining cap
220857
Swirl ring
220842
Electrode
220955
Deflector
220930
Nozzle

Hypertherm Duramax Series Specifications

General

Cooling	Air-cooled
Type	Plasma cutting torch
Series	Duramax
Compatibility	Powermax systems
Torch Lengths	15' (4.6 m), 25' (7.6 m)
Consumables	Nozzles, electrodes, shields, retaining caps, swirl rings
Torch Models	Duramax Lock
Compatible Systems	Powermax65, Powermax85, Powermax105
Nozzle Types	FineCut
Electrode Types	Standard
Shield Types	Standard
Length	15 ft (4.6 m) standard, 25 ft (7.6 m) optional
