Page 2-3
INSTALLATION
HT2000/MAX200 Water Muffler Instruction Manual
2. Verify that all components are present. Alert your distributor if any parts are
missing.
3. Inspect the power supply for any physical damage that may have occurred during
shipping. If there is evidence of damage, see the
Damage Claims
section below.
Before operating the Water Muffler system, read the
Safety
and
Operation
sections of
this manual.
Damage Claims
Claims for damage during shipment - If your unit was damaged during shipment,
you must file a claim with the carrier. Hypertherm will furnish you with a bill of lading
upon request. Call our Customer Service group at 1-800-643-0030.
INSTALLATION
To install the HT2000/MAX200 Water Muffler System, you need to install and
interconnect the following units:
• Nozzle Assembly
• Pump Unit
WARNING
Turn all power to the HT2000 or MAX200 OFF before installing water muffler!
Install the Nozzle Assembly
It is not necessary to disconnect the torch leads from the torch to install the HT2000/
MAX200 water muffler nozzle assembly:
1. Turn power to the HT2000 or MAX200 power supply OFF.
2. Remove the shield and shield cap from the HT2000 or MAX200 machine torch.
3. Select correct consumables for cutting with the water muffler system (see chart
on following page) and replace, if necessary, all torch consumables except the
W-M shield and shield cap.
For further cut chart information, refer to instruction manuals #802070: HT2000
Instruction, or #800980: MAX200 Machine Torch, or #800990: MAX200 Remote
High Frequency.
To Next Page
