HT2000/MAX200 Water Muffler Instruction Manual
WATER MUFFLER SYSTEM 600V, 3PH, 60 HZ W/HOSES
Stock No. - 034098
Stock
Number Description Quantity
020423 Cap, MAX200 shield 1
024022 Hose assembly, #12 x 50 ft. with: 1
015262 Swivel, #12 3/4 Syn hose Brs (attached to hose) 2
015264 Ferrule, 1.150 ID x .88 Brs (attached to hose) 2
046020 Hose:3/4"ID Blk 50'
024023 Hose assembly, #12 x 4 ft. with: 1
015262 Swivel, #12 3/4 Syn hose Brs (attached to hose) 1
015264 Ferrule, 1.150 ID x .88 Brs (attached to hose) 1
015052 Adapter, 3/4 NPT x #12 (attached to hose) 1
027009 Filter, 2" NPT, water 1
015578 Reducer bushing, 2" x 3/4", galv 1
015509 Nipple 2" x CL, galv 1
046020 Hose:3/4"ID Blk 4'
027012 Silicone lubricant 1
028308 Water supply, W-M, MAX200 (refer to page 4-6) 1
034148 Nozzle Assy:200A W-M 90 Deg Ftg (refer to page 4-5) 1
020566 Shield, HT2000/MAX200 W-M 200A 1
020618 Shield, HT2000/MAX200 W-M 100A 1
WATER MUFFLER SYSTEM 600V, 3PH, 60 HZ W/O HOSES
Stock No. - 034099
Stock
Number Description Quantity
020423 Cap, MAX200 shield 1
015262 Swivel, #12 3/4 Syn hose Brs 3
015264 Ferrule, 1.150 ID x .88 Brs 3
015052 Adapter, 3/4 NPT x #12 1
015578 Reducer bushing, 2" x 3/4", galv 1
015509 Nipple 2" x CL, galv 1
027009 Filter, 2" NPT, water 1
027012 Silicone lubricant 1
028308 Water supply, W-M, MAX200 (refer to page 4-6) 1
034148 Nozzle Assy:200A W-M 90 Deg Ftg (refer to page 4-5) 1
020566 Shield, HT2000/MAX200 W-M 200A 1
020618 Shield, HT2000/MAX200 W-M 100A 1
