Hypertherm HT2000 User Manual

SAFETY, INTRODUCTION & SPECIFICATIONS
Page 1-2
HT2000/MAX200 Water Muffler Instruction Manual
ELECTRIC SHOCK CAN KILL.
• Do not touch live electrical parts.
• Keep all panels and covers in place when the machine is connected to a
power source.
• Insulate yourself from work and ground: wear insulating gloves, shoes and
clothing.
• Keep gloves, shoes, clothing, work area, torch, and this machinery dry.
EXPLOSION WILL RESULT IF PRESSURIZED CONTAINERS ARE CUT.
ARC RAYS CAN INJURE EYES AND BURN SKIN.
• Wear correct eye and body protection.
NOISE CAN DAMAGE HEARING.
• Wear correct ear protection.
FUMES AND GASES CAN INJURE YOUR HEALTH.
• Keep your head out of the fumes.
• Provide ventilation, exhaust at the arc, or both to keep the fumes and
gases from your breathing zone and the general area.
• If ventilation is inadequate, use an approved respirator.
HEAT, SPLATTER AND SPARKS CAUSE FIRE AND BURNS.
• Do not cut near combustible material.
• Do not cut containers that have held combustibles.
• Do not have on your person any combustibles such as a butane lighter or
matches.
• Pilot arc can cause burns. Keep the torch nozzle away from yourself and
others when the switch is depressed.
• Wear correct eye and body protection.
WARNING
SAFETY

Hypertherm HT2000 Specifications

General

Brand	Hypertherm
Model	HT2000
Category	Water System
Language	English

Summary

Section 1 Safety, Introduction & Specifications

Safety

Covers electrical shock, explosion, arc rays, noise, fumes, heat hazards.

System Specifications

Technical details including input power, pressure, output, weight.

Section 2 Installation

Install the Nozzle Assembly

Step-by-step guide to attaching the nozzle assembly to the torch.

Pump to Water Table Connection

Connecting the pump inlet to the water table feed port.

Pump to Nozzle Assembly Connection

Routing the discharge hose from the pump to the nozzle assembly.

Connect Pump to HT2000

Electrical connection of the pump to the HT2000 power supply.

Connect Pump to MAX200

Electrical connection of the pump to the MAX200 power supply.

Test the System

Procedures for testing the installed water muffler system.

Pump Discharge Hose Checkout

Checking water recovery in festoon systems.

Install Check Valve

Section 3 Operation & Maintenance

System Operation

Pump Unit Maintenance

Suction Filter/Strainer Maintenance

Nozzle Assembly Maintenance

Nozzle Assembly Removal and Replacement

Steps for removing, disassembling, and replacing the nozzle assembly.

Section 4 Standard Components

Nozzle Assembly Components

Water Supply Components

Water Muffler Pump Assembly Components

Component list for the water muffler pump assembly.
