MAX200 Product Configuration Manual
1-1
SPECIFICATIONS
Section 1
SPECIFICATIONS
PRODUCT SPECIFICATIONS
MAX200 Power Supplies
The MAX200 is a constant current, secondary converter chopper power supply providing
continuously variable amperage from 40 amps to 200 amps. It conforms to the following
specifications:
Maximum OCV (U
0
)......................................280 VDC
Output Current (I
2
) ........................................40-200 amps
Output Voltage (U
2
) ......................................150 VDC
Duty Cycle Rating (X)...................................100% up to 30kW
Input Power (Input Voltage (U
1
) x Input Current (I
1
):
073002* ........................................................240/480 VAC, 3Ø, 60 Hz, 90/45 amps
073020**
073003* ........................................................600 VAC, 3Ø, 60Hz, 36 amps
073021**
073004* ........................................................208 VAC, 3Ø, 60Hz, 104 amps
073022**
073005* ........................................................220/380/415 VAC, 3Ø, 50 Hz, 98/57/52
073023** amps
073026* ........................................................200 VAC, 3Ø, 50 Hz, 108 amps
073024**
073200* ........................................................400 VAC - CE, 3Ø, 50 Hz, 56 amps
073213**
073036* ........................................................500 VAC, 3Ø, 50 Hz, 43 amps
073039**
* MAX200 Power Supply - comes without THC Configuration
** MAX200 Power Supply for use with the machine torch - comes with THC Configuration
