SPECIFICATIONS
MAX200 Machine Torch
Maximum cutting thickness ..........................2 inches (50 mm)
Maximum current at 100% duty cycle ..........200 amps
Plasma Gas Flow .........................................66 scfh (Air), 60 scfh (N
2
), 70 scfh (H35), 72 scfh (O
2
)
Shield Gas Flow ...........................................220 scfh (CO
2
), 280 scfh (Air), 290 scfh (N
2
)
Water Coolant Flow Rate .............................0.8 gpm (3.0 l/min)
Weight ..........................................................2-1/2 lbs. (1.1 kg)
Switch Remote (SR) V/C Control - Optional
Controls ........................................................Start button:
Activates IHS (if on) and initializes
pilot arc.
Stop button:
Deactivates main contactor in
power supply.
IHS On/Off switch:
Turns IHS system on or off.
Auto Height On/Off switch:
Activates THC in power supply.
Voltage adjust pot:
Adjusts arc cutting voltage and
displays value on LEDs.
Current adjust pot:
Adjusts arc cutting current and
displays value on LEDs.
Control Range ..............................................Current: 40 to 200 Amps
Voltage: 100 to 200 Volts
Control Resolution........................................Current: 20 Amps
Voltage: 5 Volts
Dimensions:
Width ............................................................11-1/2" ( 29 cm)
Height ...........................................................5" (13 cm)
Depth............................................................13-1/4" (34 cm)
Weight ..........................................................6 pounds (2.7 kg)
Digital Remote (DR) V/C Control - Optional
Controls ........................................................Voltage adjust pot:
Adjusts arc cutting voltage and
displays value on LEDs.
Current adjust pot:
Adjusts arc cutting current and
displays value on LEDs.
Dimensions:
Width ............................................................11-1/2" (29 cm)
Height ...........................................................3" (7.6 cm)
Depth............................................................13-3/8" (34 cm)
Weight ..........................................................5 pounds-5 oz. (2.4 kg)
