Preventive Maintenance Program

36 809490 Instruction Manual XPR

Plasma power supply to cutting table connection

Work lead (XPR170 only)

Work lead (XPR300 only)

*Leads labeled with CCC mark only.

Torch connect console to torch receptacle connection

Torch lead

Part number Type Length Part number Type Length

223617 1/0 3 m (9.8 feet) 223650* 1/0 3 m (9.8 feet)

223618 1/0 4.5 m (14.8 feet) 223651* 1/0 4.5 m (14.8 feet)

223619 1/0 7.5 m (24.6 feet) 223652* 1/0 7.5 m (24.6 feet)

223620 1/0 10 m (32.8 feet) 223653* 1/0 10 m (32.8 feet)

223621 1/0 15 m (49.2 feet) 223654* 1/0 15 m (49.2 feet)

223622 1/0 20 m (65.6 feet) 223655* 1/0 20 m (65.6 feet)

223623 1/0 25 m (82 feet) 223656* 1/0 25 m (82 feet)

223635 2/0 35 m (114.8 feet) 223668* 2/0 35 m (114.8 feet)

223636 2/0 45 m (147.6 feet) 223669* 2/0 45 m (147.6 feet)

223637 2/0 60 m (196.9 feet) 223670* 2/0 60 m (196.9 feet)

223638 2/0 75 m (246.1 feet) 223671* 2/0 75 m (246.1 feet)

Part number Type Length Part number Type Length

223628 2/0 3 m (9.8 feet) 223648 4/0 60 m (196.9 feet)

223629 2/0 4.5 m (14.8 feet) 223649 4/0 75 m (246.1 feet)

223630 2/0 7.5 m (24.6 feet) 223661* 2/0 3 m (9.8 feet)

223631 2/0 10 m (32.8 feet) 223662* 2/0 4.5 m (14.8 feet)

223632 2/0 15 m (49.2 feet) 223663* 2/0 7.5 m (24.6 feet)

223633 2/0 20 m (65.6 feet) 223664* 2/0 10 m (32.8 feet)

223634 2/0 25 m (82 feet) 223665* 2/0 15 m (49.2 feet)

223646 4/0 35 m (114.8 feet) 223666* 2/0 20 m (65.6 feet)

223647 4/0 45 m (147.6 feet) 223667* 2/0 25 m (82 feet)

Part number Length Part number Length

428383 2 m (6.6 feet) 428386 3.5 m (11.5 feet)

428384 2.5 m (8.2 feet) 428387 4.5 m (14.8 feet)

428385 3 m (11.5 feet) – –
