Document No. 480HX-HSCAM.A01
Page 6 of 9
Wired headset setup
1. Connect the detachable microphone to the headset’s microphone port. Push until the
microphone sits flush.
2. Connect the 3.5mm cable plug with the grey portion into the headset’s cable port. Push until you
feel a click and there is no visible grey portion.
3. Connect the opposite end of the 3.5mm cable to your device.
a. If you are connecting to a PC or device that has both an audio port (green)* and a
microphone port (pink)*, connect the opposite end of the 3.5mm cable to the 3.5mm PC
extension cable. Then connect the audio plug with the green stripes into the audio port
and connect the microphone plug with the pink stripes into the microphone port.
*Port colours may vary on different devices.
