11 HHT-5000/6000/8000/10000/12000 USER MANUAL
4.4 Installing the PE cable
1. Insert the grounding conductor into the suitable terminal lug and crimp the contact.
2. Align the terminal lug with the grounding conductor and the ground washer on the
screw. The teeth of the ground washer must be facing the housing.
3. Tighten it firmly into the housing (screwdriver type: T25, torque: 2.5Nm).
Information on grounding components:
Object
Description
1
Housing
2
Terminal lug with protective conductor
