Hypontech HPT-30K Series - Technical Parameter

27 User Manual
9. TECHNICAL PARAMETER
MODEL
HPT-30K
HPT-33K
HPT-36K
HPT-40K
HPT-50K
INPUT / DC
Max. PV Power / Wp
49500
54000
60000
65000
Max. Input Voltage /
V
1100
MPP Voltage Range /
V
150-1000
Full Load MPP
Voltage Range / V
330-900
330-900
380-900
430-900
500-900
Min. DC Voltage /
Start Up Voltage / V
150/180
Nominal DC-Input
Voltage / V
620
Max. Input Current /
A
30/30/30
30/30/30/30
Max. DC Short Circuit
Current / A
45/45/45
45/45/45/45
No. of Independent
MPPT Inputs
3
4
No. of PV Strings per
MPPT
2
OUTPUT / AC
Rated Power / W
30000
33000
36000
40000
50000
Max. Apparent AC
Power / VA
33000
36300
39600
44000
55000
Rated Grid Voltage /
Vac
380/400 | 3 / 3L-N-PE or 3 / 3L-PE
Rated Power
Frequency / Hz
50/60
