HySecurity SlideDriver 40 Manual

STOP BUTTON
OPEN BUTTON
CLOSE BUTTON
REMOTE OPEN AND
RADIO CONTROL
OPEN/CLOSE
1
OPEN PARTIAL
INTERLOCK OPEN
TIME CLOCK OPEN
FREE EXIT DETECTOR
DISABLE EXIT DETECTOR
DISABLE CLOSE TIMER
INSIDE OBSTRUCTION
VEHICLE DETECTOR
OUTSIDE OBSTRUCTION
VEHICLE DETECTOR
SHADOW/RESET
VEHICLE DETECTOR
SENSOR 1
SENSOR COM
DO NOT USE
DO NOT USE
DO NOT USE
CHARGER
AC LOSS
LOCK INTERLOCK
EMERG CLOSE
FIRE DEPT OPEN
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
Smart Touch Controller
LIMIT DUAL GATE
RADIO OPTIONS
DRIVE
POWER
RS485
MOTOR USER 1
USER 2
USER 3
VEHICLE DETECTORVEHICLE DETECTORVEHICLE DETECTOR
STOP/BUZZER
FREE EXIT
INSIDE OBSTR
OUTSIDE OBSTR
SHADOW RESET
WIEGAND
HySecurity
COM
NO
MX000585
VERSION
S/N
RS232
DISPLAY
VEHICLE DETECTOR
COM COMA B
RPM
COMOPEN S 1+24V +24V
STAT US
LED
24V AC Accessory power
+
2
4V D
C
COMMON
+ 24VDC
Inputs
SENSOR 2
SENSOR 3
Smart Touch Controller
RS-485
Connector
Menu
button
Select
button
Reset
button
Open
button
SA 1
SYSTEM ADDRESS
Press Select again to set gate operator's system
address (Each gate operator attached to the
same HyNet must have a unique SA number.
Choose 1, 2, 3, or 4.)
2
1
To access Installer Menu, press Menu button
twice. Then, press Reset and Open.
Press Select to navigate to Installer Menu item
"SA" System Address.
3
To exit Menu mode, press Menu. The gate
operator returns to Run mode.
4
Refer to Table 1: HyNet LED Indicators on page
2. Solid green means serial communication
is active and functioning well.
HySecurity gate operators provides a 2-wire, serial interface (RS-485 connection) which allows remote access to
one or more operators.
When the physical connection is made and protocols are established, an SA (System Address) must be assigned
for each operator through its Installer Menu.
For network communication, choosing a “SA” of 1 to 4 establishes individual network polling addresses. HyNet
only utilizes numbers 1, 2, 3, or 4.
A “SA” of zero means no network communication is desired.
5
For IP network setup, refer to the HyNet Quick
Start manual supplied in the HyNet box..
Power Supply Board
Tact
button
+24VDC Accessory Power (+)
Common Bus (-)
