3
Radio Controls
Radio Controls
No. Part Name No. Part Name No. Part Name No. Part Name
1 SK1 (Side Key 1) 6 Microphone 11 LED Indicator 16 Up Key
2 PTT Key 7 LCD Display 12 Antenna 17 Down Key
3 SK2 (Side Key 2) 8 OK/Menu Key 13
Radio On-Off/Volume Control Knob
18 Battery Latch
4 TK (Top Key) 9 Speaker 14 Accessory Jack 19 Belt Clip
5 Channel Selector Knob 10 Numeric Keypad 15 Back Key 20 Battery
