Installation User Manual
28
 Cover idle optical fiber connectors with protective caps.
Cable List
Cable-access Donor Unit Cable List
Cable
One end (at DS-9300 device) Other end
Connector Connected to …… Connected to ……
Grounding
Cable
Ring Terminal Ground Terminal Grounding Bar
RF Antenna N-M RX/TX/BS Interfaces Base Station
Power Cable 3-pin AC Connector AC 90-264 V External Power Supply
Optical Fiber SFP/SFP+ CPRI 0–3 Fiber Optic Network
Wireless-access Donor Unit Cable List
Cable
One end (at DS-9300 device) Other end
Connector Connected to …… Connected to ……
Grounding
Cable
Ring Terminal Ground Terminal Grounding Bar
RF Antenna N-M BS Interface Antenna System
Power Cable
Round Electric
Connector
AC Interfaces External Power Supply
Optical Fiber SFP/SFP+ CPRI 0–3 Interfaces Optical Fiber Network
Monitoring
Cable
8-pin/1-pin Aviation
Connector
EXM/LCT Interfaces External Monitoring Device
Remote Unit Cable List
Cable
One end (at DS-9300 device) Other end
Connector Connected to …… Connected to ……
Grounding
Cable
Ring Terminal Ground Terminal Grounding Bar
RF Antenna N-M MS Interface Antenna System
