Need help?Do you have a question about the Hytera HM785 and is the answer not in the manual?
General| Channel Capacity | 1024 |
|---|---|
| Operating Voltage | 13.6 V ± 15% |
| GPS | Yes |
| Bluetooth | Yes |
| Channel Spacing | 12.5/20/25 kHz |
| Operating Temperature | -30°C to +60°C |
| Frequency Stability | ±0.5 ppm |
| Antenna Impedance | 50 Ω |
| Modulation Limiting | ±2.5 kHz @ 12.5 kHz; ±4.0 kHz @ 20 kHz; ±5.0 kHz @ 25 kHz |
| Audio Distortion | ≤3% |
| Intermodulation | ≥65dB |
| Spurious Response Rejection | ≥70dB |
| IP Rating | IP54 |
| Frequency Range | UHF: 400-527MHz |
| Display | 2.4-inch |
| Digital Protocol | DMR |
| FM Hum & Noise | ≥40dB |
| Adjacent Channel Power | ≥60dB |
| Audio Response | +1~-3dB |
| Conducted & Radiated Emission | -36dBm ＜1GHz; -30dBm ＞1GHz |
| Adjacent Channel Selectivity | ≥60dB |
| Zone Capacity | 64 (each with a maximum of 256 channels) |
| Sensitivity (Analog) | 0.22 μV (12 dB SINAD) |
