10
The RF antenna must be purchased separately.
The GPS antenna is available only for radios with the GPS feature.
The palm microphone without keypad (with and ) is available for the conventional radio, and the one
with keypad (with and ) is for the trunking radio.
3.4 Procedure
3.4.1 Installing the TF Card
Release the latch on both sides of the plastic upper cover.
Hold the front panel, and then pull and remove the plastic upper cover.
Insert the TF card to the metal card slot properly as directed in the following figure.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hytera HM785 and is the answer not in the manual?

Hytera HM785 Specifications

General IconGeneral
Channel Capacity1024
Operating Voltage13.6 V ± 15%
GPSYes
BluetoothYes
Channel Spacing12.5/20/25 kHz
Operating Temperature-30°C to +60°C
Frequency Stability±0.5 ppm
Antenna Impedance50 Ω
Modulation Limiting±2.5 kHz @ 12.5 kHz; ±4.0 kHz @ 20 kHz; ±5.0 kHz @ 25 kHz
Audio Distortion≤3%
Intermodulation≥65dB
Spurious Response Rejection≥70dB
IP RatingIP54
Frequency RangeUHF: 400-527MHz
Display2.4-inch
Digital ProtocolDMR
FM Hum & Noise≥40dB
Adjacent Channel Power≥60dB
Audio Response+1~-3dB
Conducted & Radiated Emission-36dBm <1GHz; -30dBm >1GHz
Adjacent Channel Selectivity≥60dB
Zone Capacity64 (each with a maximum of 256 channels)
Sensitivity (Analog)0.22 μV (12 dB SINAD)
