Hytera HM785 User Manual

21

With the Keypad Mode feature enabled by your dealer, go to Menu > Settings > Basic Settings > Keypad Mode,
and then select On. On the home screen, enter the private ID, select Private ID, and then press and hold the PTT
key.
The private ID must be complied with the dialing rules. For details, consult your dealer.
Through Call Logs
Go to Menu > Call Logs, and then select the private call record.
Press and hold the PTT key.
Through One Touch Call/Menu
With the One Touch Call/Menu feature enabled, press the preprogrammed One Touch Call/Menu key, and then press
and hold the PTT key.
6.2.1.2 Trunking Mode
Through Preset Contact
Press and then rotate the Smart knob to select the private contact.
Press the PTT key.
Through Contact List
Do either of the following:

Press the Back/Subgroup key or the preprogrammed Current Subgroup Contact or Contact List key.

Go to Menu > Contact > Favorite/Private.
Select the private contact.
Press the P5/Answer key on the radio, or press the Answer key or the PTT key on the palm microphone.
Through Manual Dialing
On the home screen, enter the private ID through the keypad on the palm microphone.
Do either of the following:

Press the P5/Answer key on the radio.

Press the Answer key, , or the PTT key on the palm microphone.
The private ID must be complied with the dialing rules. For details, consult your dealer.
Through Call Logs
Do one of the following:

Hytera HM785 Specifications

General

Channel Capacity	1024
Operating Voltage	13.6 V ± 15%
GPS	Yes
Bluetooth	Yes
Channel Spacing	12.5/20/25 kHz
Operating Temperature	-30°C to +60°C
Frequency Stability	±0.5 ppm
Antenna Impedance	50 Ω
Modulation Limiting	±2.5 kHz @ 12.5 kHz; ±4.0 kHz @ 20 kHz; ±5.0 kHz @ 25 kHz
Audio Distortion	≤3%
Intermodulation	≥65dB
Spurious Response Rejection	≥70dB
IP Rating	IP54
Frequency Range	UHF: 400-527MHz
Display	2.4-inch
Digital Protocol	DMR
FM Hum & Noise	≥40dB
Adjacent Channel Power	≥60dB
Audio Response	+1~-3dB
Conducted & Radiated Emission	-36dBm ＜1GHz; -30dBm ＞1GHz
Adjacent Channel Selectivity	≥60dB
Zone Capacity	64 (each with a maximum of 256 channels)
Sensitivity (Analog)	0.22 μV (12 dB SINAD)
