Hytera PD505 User Manual

4
Contents
1. Items in the Package ------------------------------------1
2. Product Overview -----------------------------------------2
Product Controls ---------------------------------------------------2
Programmable Keys ----------------------------------------------3
3. Before Use --------------------------------------------------3
Assembling the Radio --------------------------------------------3
Charging the Battery ----------------------------------------------4
Checking the Battery Power ------------------------------------5
4. Status Indication ------------------------------------------5
LED Indicator -------------------------------------------------------5
5. Basic Operations -----------------------------------------6
Powering On/Off ---------------------------------------------------6
Adjusting the Volume ---------------------------------------------6
Selecting a Zone ---------------------------------------------------6
Selecting a Channel -----------------------------------------------6
6. Call Services------------------------------------------------7
Calling on Digital Channel ----------------------------------7
Calling on Analog Channel (No Signaling) --------------8
7. Feature Description --------------------------------------8
8. Troubleshooting -------------------------------------------9
9. Care and Cleaning ----------------------------------------10
10. Optional Accessories ----------------------------------11

Hytera PD505 Specifications

General

Channel Capacity	32
Zone Capacity	3
Operating Voltage	7.4 V
Dimensions	115 x 54 x 27 mm
Weight	260 g
IP Rating	IP54
Storage Temperature	-40°C to +85°C
Shock & Vibration	MIL-STD-810 C/D/E/F/G
Frequency Range	UHF: 400-470 MHz; VHF: 136-174 MHz
Channel Spacing	12.5/25 kHz
Digital Protocol	DMR
Operating Temperature	-30°C to +60°C
Humidity	95% RH
RF Power Output	UHF: 1W/4W; VHF: 1W/5W
Battery	1500mAh Li-Ion battery
Display	No
Keypad	No
