Items in the Package
Please unpack carefully and check that all items listed
below are received. If any item is missing or
damaged, please contact your dealer.
Radio Battery Charger
Power Adapter Antenna Belt Clip
Strap Documentation Kit
· The pictures in this manual are for
reference only.
· The frequency band is marked on the
antenna label; if unavailable, see the label
on the radio.
Product Overview
Product Controls
No. Part Name No. Part Name
1
Side Key 1 (SK1)
12
LED Indicator
2
Push-to-Talk (PTT)
Key
13
Antenna
3
Side Key 2 (SK2)
14
On-Off/Volume
Control Knob
4
Top Key (TK)
15
Accessory
Connector
5
Channel Selector
Knob
16
Back Key
6
Microphone
17
P2 Key
7
LCD Display
18
Up Key
8
OK/Menu Key
19
Down Key
9
P1 Key
20
Battery Latch
10
Speaker
21
Belt Clip
11
Numeric Keypad
22
Battery
2
To Next Page
