The Stealth hydraulic limited-clearance wrench is a tool used for both your torque and
tension applications. Different reaction arms and sockets can be used with the tool.
HYTORC hydraulic tools have an accuracy of ± 3%.
3.2
Overview
1
Electric pump unit
3
Hydraulic limited-clearance wrench
2
Twin hose
