5-15
DISASSEMBLY
DISASSEMBLY
Disassemble steering column from
steering unit and place the steering unit in
the holding tool.
Screw out the screws in the end cover
(6-off plus one special screw).
4)
4)
(1)
Remove the end cover, sideways. (2)
Lift the gearwheel set(With spacer if fitted)
off the unit.
Take out the two O-rings.
(3)
Remove cardan shaft. (4)
5-72(1)
5-72(2)
5-72(3)
5-72(4)
