1-9
4. TIGHTENING TORQUE FOR MAJOR COMPONENTS
4. TIGHTENING TORQUE FOR MAJOR COMPONENTS
No. Items Size kgf · m lbf · ft
1
Engine
Engine mounting nut (bracket-frame) M12×1.25 9.7±1.9 13.7±13.7
2 Engine mounting bolt (engine-bracket) M10×1.25 7.4±1.5 10.8±10.8
3 Engine mounting nut (mount-frame) M12×1.75 12.8±3 92.6±21.7
4 Radiator mounting bolt, nut M 8×1.25 2.5±0.5 18±3.6
5 Torque converter mounting bolt (8EA) M10×1.25 7.4±1.5 53.5±10.8
6
Hydraulic
system
MCV mounting bolt M10×1.5 4±0.5 29±3.6
7 Steering unit mounting bolt M10×1.5 6.9±1.4 50±10.1
8
Power
train
system
Transmission mounting bolt, nut M16×2.0 7.5 54
9 Drive axle mounting bolt, nut M20×1.5 65±3 470±21.7
10 Steering axle mounting bolt M20×2.5 58±8.5 420±61.5
11 Front wheel mounting nut M20×1.5 40±10 289±72.3
12 Rear wheel mounting nut M14×1.5 18±2 130±14.5
13
Others
Counterweight mounting bolt M30×3.5 215±33 1555±239
14 Operator's seat mounting nut M 8×1.25 2.5
±0.5 18.1±3.6
15 Head guard mounting bolt, nut M12×1.75 6.2 44.8
