2-16
Rear wheel
Remove mounting bolt and hub nut with
socket wrench and then carefully take out
the tire assembly.
(2)
20D7RE28
Hose
Drain hydraulic oil in the hoses and
cylinders before removing them.
Remove the fitting and then disconnect
the hoses.
(3)
20D7RE29
Mounting bolt
Put a block under the steering axle,
support on a truck, an raise the frame with
a crane. Remove the mounting bolts
installing to the frame, and pull out to the
rear.
There are shims between the support and
steering axle to prevent play.
(4)
20D7RE30
