Maintenance
527
Engine compartment sub fuse panel (Disel Engine)
No. Fuse rating Fuse Symbol Circuit Protected Relay Symbol Relay Type
1 50A PTC Heater Relay #1 MICRO PLUG
2 50A PTC Heater Relay #2 MICRO PLUG
3 50A PTC Heater Relay #3 MICRO PLUG
4 30A Fuel Filter Heater Relay MICRO PLUG
5 80A Glow Relay Unit - -
No. Fuse rating Symbol Fuse Name Circuit Protected
FUSE
14 15A DEICER RLY. 10 (Front Wiper Deicer Relay)
15 10A STOP LAMP Stop Lamp Switch, ICM Relay Box (DBC Relay)
16 10A B+ SENSOR Battery Sensor (G4KD/D4HA)
17 10A 4WD 4WD ECM
18 7.5A ECU 2
RLY. 11 (ATM P/N Relay), RLY. 4 (Start Relay), ECM/PCM,
Multifunction Switch (G4KD), Mass Air Flow Sensor (D4FD/D4HA)
19 7.5A ABS
ESP Control Module, ABS Control Module, Multipurpose Check Connector,
Fuel Filter Warning Sensor (D4FD/D4HA), Glow Relay Unit (D4HA),
Diesel Box (RLY. 4 - Fuel Filter Heater Relay)(D4FD/D4HA)
20 7.5A TCU 2 Transaxle Range Switch(G4KD/D4HA), TCM (D4HA), Vehicle Speed Sensor
To Next Page
