Be careful not to screw the I LOCK IT GPS too tight. This could
cause difficulties in moving the locking bar.
Check manually that the I LOCK IT GPS can be tilted back and
forth. The mudguard should not hinder the movement.
MOUNTING AT BIKE WITHOUT THREADED SOCKETS
If your bike does not have threaded sockets for mounting
I LOCK IT GPS, then I LOCK IT GPS can be easily and safely
mounted with the optional installation adapters.
Please follow the steps below:
FIRST SET-UP
The installation adapters have flexible screw
holders that can be adjusted laterally. This allows
even more variety in the frame width of the bike.
I. Attach the appropriate installation adapter to one of the
frame struts.
II. Place the plastic bands around the strut and then through
the openings on the installation adapter.
III. Insert the plastic screws (1) into the installation adapter.
IV. Use a suitable screwdriver to tighten the installation adapter
by turning the plastic screw.
