MAN048ING16
3.8.5–CONNECTTHETERMINALFROMTHE
IGNITIONWITH THE 8 POLE TERMINAL ON
THEHARNESSSEEFIG.20).
CONNECTTHEONEWAYTERMINALFROM
THE ELECTRIC STARTER WITH THE ONE
WAY TERMINAL ON THE HARNESS (SEE
FIG.21).
ATTENTION:
MAKE SURE THAT THE FIXING TONGUES
ARE PROPERLY INSERTED TO
GUARANTEE THE BEST POSSIBLE
CONNECTIONOFTHETERMINALS.
3.8.6 CHECK THE ELECTRIC STARTER
CABLE FIXING (SEE FIG. 22) AND
COMPLETE THE FIXING OF THE HARNESS
(SEEFIG.23).
ATTENTION:
NEVER LET THE HARNESSGET IN TOUCH
WITHTHE GROUNDOR WITH A ROTATI NG
PARTASITCOULDBEDAMAGEDBEYOND
REPAIR.
.
Fig.21
Fig.23
Fig.22
