MAN048ING17
3.8.7 FIX THE HARNESS GROUND CABLE
WITH THE EYELET TERMINAL (Ø 6.5mm),
ON THE ENGINE CRANKCASE, BY MEANS
OF THE PROPER THREADED HOLE (SEE
FIG.24).
M6x12SCREW
TORQUEAT8÷10Nm(70÷90inlb)
ATTENTION:
THIS OPERATION IS EXTREMELY
IMPORTANT AS AN UNCERTAIN
GROUNDING CO ULD DAM AGE THE
POWERPACKBEYONDREPAIR.
5mmALLEN
3.8.8 FIX THE EYELET TERMINAL (Ø 7mm),
OF THE SECOND GROUND CABLE IN THE
HARNESS(CLOSETOTHECOILCABLE)TO
THE H.T. COIL BY MEANS OF THE M6 NUT
FIXINGTHECOIL(SEEFIG.25).
TORQUEAT8÷10Nm(70÷90inlb)
ATTENTION:
THIS OPERATION IS EXTREMELY
IMPORTANT AS AN UNCERTAIN
GROUNDINGCOULDDAMAGETHEPOWER
PACKBEYONDREPAIR.
10mmBOXWRENCH
3.8.9 CONNECT THE H.T. COIL CABLE TO
THEHARNESSTERMINAL(SEEFIG.26).
ATTENTION:
FASTENTHECOILCABLEWITHAPLASTIC
CLAMP TO AVOID THAT EVENTUAL
VIBRATIONS MIGHT DISCONNECT THE
TERMINALS( SEEFIG.27).
Fig.24
Fig.25
Fig.27
Fig.26
