MAN048ING19

3.8.13 CONNECT THE CABLE FROM THE

STARTING ASSEMBLY WITH THE 8 POLE

TERMINAL IN THE WIRING HARNESS (SEE

FIG.32).

ATTENTION:

MAKE SURE THAT THE FIXING TONGUES

ARE PROPERLY INSERTED TO

GUARANTEE THE BEST POSSIBLE

CONNECTIONOFTHETERMINALS.

3.8.14 ATTACHTHEDUALLOCKFIXING

STRAP(CLOSETOTHESTEERING

COLUMN)ANDPLACETHEELECTRONIC

BOXANDTHESTARTERRELAY(SEEFIG.

33).

NOTE:

CLEANANDDEGREASETHEFAIRING

FIXINGSURFACEWHERETHESTRAPIS

TOBEPLACEDTOGUARANTEETHEBEST

POSSIBLESTRAPATTACHMENT.

3.8.15DRILLAFEWHOLESINTHEFAIRING

TOATTACHTHECABLESWITHPLASTIC

CLAMPS(SEEFIG.34).

3.8.16ATTACHTHEDUALLOCKFIXING

STRAPUNDERTHEFRONTFAIRING

(CLOSETOTHEBATTERY)ANDPLACE

THEFUSEHOLDER(SEEFIG.35).

NOTE:

CLEANANDDEGREASETHEFAIRING

FIXINGSURFACEWHERETHESTRAPIS

TOBEPLACEDTOGUAR ANTEETHE

BESTPOSSIBLESTRAPATTACHMENT.

Fig.32

Fig.33

Fig.34

Fig.35
