AHU 1600 - Heating Capacity (Entering Dry Bulb Temperature 70°F) @ 1600 CFM
Entering Water Temperature 3 GPM 4 GPM 5 GPM
195°F (90°C) 96.9 MBH 106.7 MBH 113.2 MBH
190°F (88°C) 92.9 MBH 102.3 MBH 108.6 MBH
180°F (82°C) 84.9 MBH 93.5 MBH 99.3 MBH
170°F (77°C) 77.0 MBH 84.8 MBH 90.0 MBH
160°F (71°C) 69.1 MBH 76.1 MBH 80.8 MBH
150°F (66°C) 61.2 MBH 67.4 MBH 71.6 MBH
140°F (60°C) 53.3 MBH 58.8 MBH 62.5 MBH
130°F (54°C) 45.5 MBH 50.2 MBH 53.4 MBH
120°F (49°C) 37.7 MBH 41.6 MBH 44.3 MBH
110°F (43°C) 30.0 MBH 33.2 MBH 35.3 MBH
Table 3 Heating Capacity rating at 1600 scfm (standard cubic feet / minute) - AHU 1600
AHU 2000 LV- Heating Capacity (Entering Dry Bulb Temperature 70°F) @ 2000 CFM
Entering Water Temperature 3 GPM 4 GPM 5 GPM
195°F (90°C) 105.2 MBH 117.4 MBH 125.8 MBH
190°F (88°C) 100.8 MBH 112.5 MBH 120.6 MBH
180°F (82°C) 92.1 MBH 102.9 MBH 110.3 MBH
170°F (77°C) 83.5 MBH 93.2 MBH 100.0 MBH
160°F (71°C) 74.9 MBH 83.6 MBH 89.7 MBH
150°F (66°C) 66.3 MBH 74.1 MBH 79.5 MBH
140°F (60°C) 57.8 MBH 64.6 MBH 69.3 MBH
130°F (54°C) 49.3 MBH 55.1 MBH 59.1 MBH
120°F (49°C) 40.9 MBH 45.7 MBH 49.1 MBH
110°F (43°C) 32.5 MBH 36.4 MBH 39.1 MBH
Table 4 Heating Capacity rating at 2000 scfm (standard cubic feet / minute) - AHU 2000
