Required if the boiler or the combi boiler does not have control of the pump
Optional: 'G' for fan-only operation and 'C' for t-stat common
Dry contact from the air handler to the boiler or combi boiler that enables a call for heat
The reversing valve operation is selectable with the AHU app: the default setting
energizes the O/B terminal during cooling
Required: the outdoor sensor for balance point control of backup heat source is available
separately as IBC outdoor sensor kit P-9067.
Required: sensors for cooling applications are available separately as IBC A/C sensor kit
P-1015
Required: if outdoor unit requires a dry contact; typical of bonded controls. Check your
outdoor unit installation manual.
Figure 35 Single-stage heat pump with a boiler or combi boiler as backup wiring - with isolation relays
Worked examples:
1. Wiring single-stage heating with a boiler or combi boiler on page 37
2. Wiring single-stage heating with a tankless water heater as a heat source on page 38
3. Wiring single-stage heating with boiler or combi boiler, and single-stage cooling on page 39
4. Wiring two-stage cooling with a boiler or combi boiler heating using a 2-stage thermostat on
page 40
5. Wiring single-stage heat pump with a boiler or combi boiler as backup on page 41
6. Wiring single-stage heat pump with a boiler or combi boiler as backup (emergency heat on
T-stat) on page 43
7. Wiring two-stage heat pump with a boiler or combi boiler as backup (2-stage thermostat) on
page 45
8. Wiring two-stage heat pump (2-stage thermostat) on page 47
9. Wiring single-stage heating, single-stage cooling, with the tankless water heater as the
heat source on page 48
10. Wiring two-stage cooling with a tankless water heater as a heat source on page 49
11. Wiring single-stage heat pump with a tankless water heater as a backup on page 50
12. Wiring two-stage heat pump with a tankless water heater as a backup on page 52
13. Wiring make-up air with a boiler or a combi as a heat source on page 54
2.8.0.1 Tankless Mode
Tankless Mode should always and only be chosen when a tankless water heater is a heat source.
Tankless mode recognizes that when DHW is being drawn the water heater is in effect temporarily
unavailable, so reduces the fan speed when outlet temperature drops.
