6.
Plug in all connectors (temperature sensor from the coil, connector for the transformer,
connector for fan power, connector for fan control, connector to the door switch, and the
ground wire connector).
Now you must use the air handler app (IBCconnect to program the model name, mode, and
change default settings (if desired).
7. To set the model, mode, and to configure settings:
a. Open the IBCconnect app on your phone.
b. Go to Configure AHU.
c. From the AHU Model dropdown, select the model.
5.3.3 Replacing the control board
