Item

Number

P-Kit Number Description

100 P-1000 Door assembly - AHU 800

P-1019 Door assembly - AHU 1200

P-1020 Door assembly - AHU 1600, AHU 2000

110 P-1010 Air filter size 25 x 16 x 1 - AHU 800

Air filter size 25 x 20 x 1 - AHU 1200 LV, AHU 1200, AHU

1600, AHU 2000

120 P-1008 Door switch, SPST-NO. 15A 125V

Wiring harness

130 P-1011 Supply water temperature sensor

140 P-1012 Temperature sensor and grommet

150 P-1011 Return water temperature sensor

160 P-1003 Hot water coil 2-ton appliance - AHU 800

P-1021 Hot water coil 3-ton appliance - AHU 1200

P-1022 Hot water coil 4-ton / 5-ton appliance - AHU 1600, AHU

2000 low velocity

170 P-1005 Transformer 40VA 120V

180 P-1001 Control board

190

P-1007

Filter bracket wing nuts x 4

200 Air filter lower bracket

210 Air filter upper bracket

220

P-1017 Coil hex bolts, hex nut, washer x 2

Fan plate hex bolts, washer x 2

230 P-1004 Fan and motor assembly - AHU 800

P-1023 Fan and motor assembly - AHU 1200 low velocity

P-1024 Fan and motor assembly - AHU 1200

P-1025 Fan and motor assembly - AHU 1600

P-1026 Fan and motor assembly - AHU 2000 low velocity

240 P-1009 Fan wiring grommet

250 P-1009 Sensor wiring harness

260 P-1017 Door thumb screws x 2

P-1015 A/C Freeze sensor kit

* P-1017 = Part of the hardware kit

7 Air handling appliance - parts diagram
