IBC DC Series - Air Handler and Direct Domestic Hot Water

1-27
INSTALLATION
DC SERIES BOILERS / WATER HEATERS DC 15-95, DC 15-96, DC 20-125, DC 33-160
Figure 29a: Air handler and direct domestic hot water – parallel
piping for low head loss heat emitter concept drawing. This
drawing is only a simple schematic guide.
Figure 29b: Air handler and direct domestic hot water – primary/
secondary concept drawing. This drawing is only a simple
schematic guide.
Figure 28: Typical two temperature space heating piping concept with indirect domestic
hot water – concept drawing. This drawing is only a simple schematic guide.
