IBC DC Series User Manual

6-5
DIAGRAMS
DC SERIES BOILERS / WATER HEATERS DC 15-95, DC 15-96, DC 20-125, DC 33-160
Diagram 6.2-2: Boiler assembly parts list (refer to Diagram 6.1-1 on opposite page)
Some parts are available in Kits.
Please visit www.ibcboiler.com
for more information.
ITEM NO. PART NO. DESCRIPTION QTY
10 240-067 IGNITOR 1
20 250-622 GASKET, IGNITOR 1
30 250-623 VIEWPORT HOLDER 1
40 250-624 GASKET, VIEWPORT HOLDER 1
50 250-625 GASKET, VIEWPORT GLASS 1
60 250-626 VIEWPORT GLASS 1
70
170-018 HEAT EXCHANGER DC 96, 125
1
170-019 HEAT EXCHANGER DC 160
80 250-689 GASKET, H.Ex. FRONT PANEL, DC/HC 96, 125, 160 1
90 180-114 BURNER 1
100 250-646 GASKET, BURNER 1
115 XXX GASKET, FAN - DISCONTINUED MODEL
110 250-627 GASKET, FAN 1
120 240-068 TORIN FAN 1
130 250-633 GASKET, DHW WATER PIPE 3
140 250-634 GASKET, PUMP 2
150
180-196 VENTURI, 510, DC/HC 96
1180-112 VENTURI, 362, DC/HC 160
180-141 VENTURI, 471, DC/HC 125
155 250-733 GAS LINE, UPPER, DC/HC 96, 125, 160 1
160
180-095 ORIFICE, 505, NATURAL GAS, DC/HC 95, 96
1
180-142 ORIFICE, 550, NATURAL GAS, DC/HC 125
180-108 ORIFICE, 725, NATURAL GAS, DC/HC 160
180-198 ORIFICE, 392, PROPANE, DC/HC 95, 96
180-143 ORIFICE, 460, PROPANE, DC/HC 125
180-096 ORIFICE, 580, PROPANE, DC/HC 160
170 150-175 O-RING FOR ORIFICE 1
175 150-206 GASKET, GAS VALVE, INLET 1
180 180-097 GAS VALVE 1
190 240-069 GAS VALVE CABLE/INGITION MODULE 1
200 250-628 GAS LINE, LOWER 1
210 240-070 DHW TEMPERATURE SENSOR 1
220 250-629 SUPPLY PIPE, DHW 1
230 250-630 RETURN PIPE, DHW 1
235
180-134 FLOW RESTRICTOR, DC 124, 125, 160
1180-135 FLOW RESTRICTOR, DC 106
180-140 FLOW RESTRICTOR, DC 84
240 240-071 WATER FLOW SENSOR 1
250 250-631 RETURN PIPE 1
260 180-098 PUMP 1
270 500-074 DOOR ASSEMBLY, DC/HC 96, 125, 160
280
500-116 CONTROLLER ASSEMBLY, DC/HC 95, 96
1500-053 CONTROLLER ASSEMBLY, DC/HC 160
500-086 CONTROLLER ASSEMBLY, DC/HC 125
290 190-123 CONDENSATE PIPE ASSEMBLY 1
300 190-124 SEAL, COND. PIPE TO BOTTOM PAN 1
310 180-100 BOTTOM PAN, HEAT EXCHANGER 1
320 240-076 VENT HIGH LIMIT SWITCH 1
330 190-119 FITTING, 1/2" NPT-M 1
340 190-120 FITTING, 3/4" NPT-M 2
350 190-121 FITTING, 1" NPT-M 2
360 180-113 CONDENSATE TRAP, LONG, DC SERIES 1
370 250-638 CONDENSATE TRAP HOOK 1
380 240-072 WATER PRESSURE SENSOR TYPE LWCO 1
385 150-204 C-CLIP, WATER PRESSURE SENSOR 1
390 240-073 WATER TEMPERATURE SENSOR 2
395 150-221 CLIP, WATER TEMPERATURE SENSOR 2
400 250-632 SUPPLY PIPE 1
410 250-635 GASKET, SUPPLY PIPE 1
420 250-675 EXHAUST DUCT, INTERNAL, DC/HC 96, 125, 160 1
430 250-636 EXHAUST DUCT 1
440 250-637 INTAKE DUCT 1
